The PI3PCIE3242ZLE is a high-performance PCIe Gen3/4 ReDriver from Pericom. This device is designed to improve signal integrity in high-speed PCIe applications by compensating for channel losses. It supports data rates up to 8Gbps (Gen3) and 16Gbps (Gen4) and is suitable for applications such as servers, workstations, and storage systems where signal integrity over longer distances is critical.

Applications

• Servers
• Workstations
• Storage Systems
• Motherboards
• PCIe Expansion Cards
• High-Speed Data Acquisition Systems

Features

• PCIe Gen3/4 Compliant: Supports data rates up to 8Gbps (Gen3) and 16Gbps (Gen4).
• Integrated ReDriver: Compensates for channel losses and ISI.
• Adjustable Equalization and Output Swing: Allows for fine-tuning of the signal for optimal performance.
• Low Power Consumption: Minimizes power dissipation in high-performance systems.
• Hot-Plug Support: Ensures seamless integration and removal of devices.
• Transparent Operation: Requires no software or driver support.
• Small Package Size: Facilitates compact board designs.

Benefits

• Improved Signal Integrity: ReDriver functionality ensures high-quality PCIe signal transmission.
• Extended Trace Length: Allows for longer PCB traces without signal degradation.
• Enhanced System Performance: Supports high-speed data transfer rates.
• Reduced System Cost: Eliminates the need for expensive low-loss PCB materials.
• Increased System Reliability: Hot-plug support ensures seamless operation.

Additional Details

The PI3PCIE3242ZLE is designed to be transparent to the system, meaning that it requires no additional software or driver support. It automatically adapts to the signal characteristics and compensates for losses, ensuring reliable data transmission. The adjustable equalization and output swing features allow for fine-tuning of the signal to optimize performance based on the specific application requirements. The device's low power consumption makes it suitable for use in high-performance systems where power efficiency is important. With its small package size, the PI3PCIE3242ZLE can be easily integrated into compact board designs. It is essential for maintaining signal integrity in systems utilizing PCIe Gen3 and Gen4 interfaces.
