The PAM8006HR is a filter-less, high efficiency, 3W stereo Class-D audio amplifier from Power Analog Microelectronics. It's designed to drive speakers directly without the need for output filters, reducing component count and cost. This amplifier is ideal for portable audio devices and other low-power applications requiring high-quality sound.

Applications:

• Portable Media Players (PMPs)
• MP3 Players
• Mobile Phones
• Tablet Computers
• USB Speakers
• Toys and Games

Features:

• 3W Stereo Output at 10% THD+N with a 4Ω Load
• Filter-less Class-D Architecture
• High Efficiency (typically 90%)
• Low THD+N (typically 0.1%)
• Short-Circuit Protection
• Thermal Shutdown Protection
• Over-Current Protection
• Under-Voltage Lockout (UVLO)
• Available in a SOP-16 Package

Benefits:

• High-quality audio reproduction with low distortion
• Extended battery life due to high efficiency
• Reduced component count and cost due to filter-less design
• Robust protection features prevent damage to the amplifier and speakers
• Small package size enables use in space-constrained applications
• Simplified design and layout

Additional Details:

The PAM8006HR operates from a single power supply, typically in the range of 2.5V to 5.5V. The filter-less Class-D architecture eliminates the need for external LC filters, reducing BOM cost and board space. The amplifier incorporates comprehensive protection features, including short-circuit protection, thermal shutdown protection, and over-current protection, ensuring reliable operation even under fault conditions. The UVLO feature prevents the amplifier from operating when the supply voltage is too low, preventing damage to the speakers.

The PAM8006HR's high efficiency minimizes power dissipation, making it an excellent choice for battery-powered devices. Its low THD+N ensures clear and accurate audio reproduction. The device is available in a small SOP-16 (Small Outline Package) making it easy to integrate into compact designs.
