Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - AC DC Converters, Offline Switches
Mfr Power Integrations
Series LinkSwitch®-TN
Package Tube
Product Status Discontinued
Output Isolation Non-Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Buck, Buck-Boost, Flyback
Duty Cycle 69%
Frequency - Switching 66kHz
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Temperature Range - Operating -40°C ~ 150°C (TJ)
Package / Case 8-SOIC (0.154", 3.90mm Width), 7 Leads
Supplier Device Package SO-8C
Mounting Type Surface Mount
Base Product Number LNK306
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 187982-LNK306DN
Ultra Librarian 3D Model Ultra Librarian LNK306DN CAD Model

Description

The LNK306DN is an integrated circuit designed for power management applications in AC-DC converters. It belongs to the LinkSwitch®-TN series by Power Integrations.

  • Package: 8-SOIC (7 leads)
  • Duty Cycle: 69%
  • Output: Non-isolated
  • Switches: Internal
  • Breakdown Voltage: 700V
  • Topologies: Buck, Buck-Boost, and Flyback
  • Fault Protection: Current limiting, open loop, over temperature, and short circuit
  • Operating Temperature Range: -40°C to 150°C
  • Usage: Widely used in power management systems
  • Performance: Reliable
