Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Active
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 725V
Topology Flyback
Duty Cycle 78%
Frequency - Switching 66kHz, 132kHz
Power (Watts) 244W
Fault Protection Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit
Control Features Frequency Control
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package eSIP-7C
Mounting Through Hole
Win Source Part Number 043245-TOP271EG
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TOP271
Introduction Date March 02, 2010
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian TOP271EG CAD Model

Description

The TOP271EG is a high-performance integrated circuit manufactured by Power Integrations. It is designed for use in offline switchers and is known for its high power output and excellent fault protection features.

  • Power Rating: 244W
  • Isolation: true
  • Voltage Breakdown Rating: 725V
  • Operating Frequency: 66kHz or 132kHz
  • Supply: limited
  • Applications: high power output and excellent fault protection
