Products specifications

Category Transformers - Pulse Transformers
Mfr Pulse
Package Tape & Reel
Product Status Obsolete
Transformer Type LAN 10/100 Base-T
Mounting Type Surface Mount
Size / Dimension 0.500" L x 0.280" W (12.70mm x 7.11mm)
Height - Seated (Max) 0.235" (5.97mm)
Temperature Range - Operating 0°C ~ 70°C
Standard Package 600 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.2000
Win Source Part Number 139638-H1102T
Ultra Librarian 3D Model Ultra Librarian H1102T CAD Model

Description

The 139638-H1102T is a pulse transformer designed for LAN 10/100 Base-T applications. It is a surface mount transformer with a size of 0.500" L x 0.280" W (12.70mm x 7.11mm). With a maximum seated height of 0.235" (5.97mm), this transformer provides reliable performance in a compact package. It operates in a temperature range of 0°C to 70°C, making it suitable for a wide range of applications. Manufactured by Pulse, the 139638-H1102T comes in tape & reel packaging with a standard package of 600 pieces. Although this product is currently obsolete, it was widely used in networking equipment for data transmission. Its compact size and high performance made it a popular choice among manufacturers.
