MP256W Goodwork Semiconductor Co., Ltd .
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr Rectron USA
Package Tray
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 600 V
Current - Average Rectified (Io) 25 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 12.5 A
Current - Reverse Leakage @ Vr 5 µA @ 600 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-Square, MP-25W
Supplier Device Package MP-25W
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 643374-MP256W
Ultra Librarian 3D Model Ultra Librarian MP256W CAD Model

Description

The 643374-MP256W is a single-phase bridge rectifier diode suitable for standard applications in electronic circuits. Manufactured by Rectron USA.

  • Average Rectified Current: 25 A
  • Maximum Forward Voltage: 1.1 V @ 12.5 A
  • Reverse Leakage Current: 5 µA @ 600 V
  • Peak Reverse Voltage: 600 V
  • Mounting Type: Through Hole
  • Package: 4-Square, MP-25W
  • Operating Temperature Range: -55°C to 150°C
