Products specifications

Manufacturer Rohm Semiconductor
Win Source Part Number 1151208-BA7657F
Manufacturer Homepage www.rohm.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BA7657F CAD Model

Description

The BA7657F is a single-channel video amplifier IC manufactured by Rohm Semiconductor. It's specifically designed for use in video signal processing applications, offering high performance and reliability in a compact package.

Applications:

  • Video Cameras: Amplifies video signals in security cameras and camcorders.
  • DVD Players/Recorders: Used in DVD players and recorders to process and amplify video signals for output.
  • Television Sets: Employed in TVs to enhance video signals before display.
  • Gaming Consoles: Integrates into gaming consoles for video signal amplification.
  • Automotive Displays: Utilized in automotive infotainment systems for clear video output.

Features:

  • Single-Channel Video Amplifier: Designed for amplifying one video signal.
  • High Bandwidth: Supports high-frequency video signals.
  • Low Power Consumption: Optimized for low power operation.
  • Input Clamp Circuit: Prevents input signal overload.
  • Output Short-Circuit Protection: Protects the IC from output short circuits.
  • Operating Temperature Range: -25°C to +75°C
  • Package: SOP-8 package.

Benefits:

  • Improved Video Quality: Enhances video signal strength for clearer images.
  • Reliable Performance: Designed for stable and consistent operation.
  • Compact Design: Small package size for space-saving applications.
  • Easy Integration: Simple to integrate into existing video systems.
  • Protection Features: Built-in protection against input overload and output short circuits.

Additional Details:

The BA7657F operates on a single 5V power supply. It features an internal clamp circuit to protect the input stage from excessive voltage levels. The IC is housed in a compact SOP-8 (Small Outline Package) making it suitable for high-density circuit board designs. It's designed to meet the stringent requirements of video applications, providing clean and amplified video signals.
