Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Rohm Semiconductor
Package Tape & Reel
Product Status Not For New Designs
Motor Type - Stepper Multiphase
Motor Type - AC, DC Brushless DC (BLDC)
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (3)
Interface Logic
Technology NMOS
Applications Fan Motor Driver
Current - Output 2.5A
Voltage - Supply 13.5V ~ 400V
Voltage - Load 600V
Temperature Range - Operating -20°C ~ 100°C
Mounting Type Surface Mount
Package / Case 54-SOP (0.449", 11.40mm Width), 36 Leads
Supplier Device Package SSOP-A54_36
Base Product Number BM6209
Standard Package 1,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 864437-BM6209FS-E2
Ultra Librarian 3D Model Ultra Librarian BM6209FS-E2 CAD Model

Description

The BM6209FS-E2 is a power management integrated circuit designed for motor drivers and controllers manufactured by Rohm Semiconductor.

  • Series: Does not belong to any specific series
  • Package: Tape and reel
  • Package Quantity: 1,000 pieces
  • New Designs: Not for new designs
  • Application: Fan motor driver
  • Features: Fully integrated control and power stage
  • Output Configuration: Half bridge
