Products specifications

Manufacturer SamHop
Win Source Part Number 1262001-STS2302A
Manufacturer Homepage www.samhop.com.tw
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian STS2302A CAD Model

Description

The STS2302A is a P-Channel enhancement mode power MOSFET produced by SamHop. This device utilizes advanced trench technology to provide excellent RDS(ON), low gate charge, and fast switching speed. It's designed for use in load switching, PWM applications, and general-purpose amplification.

Applications

  • Load Switching
  • PWM Applications
  • DC-DC Converters
  • Battery Management Systems

Features

  • P-Channel MOSFET
  • Low RDS(ON) – Reduces power loss and improves efficiency.
  • Low Gate Charge – Enables fast switching and reduces driver power requirements.
  • Fast Switching Speed – Improves performance in high-frequency applications.
  • Trench Technology – Provides superior performance and reliability.
  • RoHS Compliant – Environmentally friendly.

Benefits

  • Improved Efficiency: Low RDS(ON) minimizes power dissipation, leading to higher efficiency in power conversion applications.
  • Fast Switching: Reduced gate charge allows for quicker switching times, improving performance in PWM and high-frequency circuits.
  • Simplified Design: Low gate drive requirements simplify driver circuit design and reduce component count.
  • Enhanced Thermal Performance: Efficient heat dissipation contributes to stable and reliable operation.
  • Environmentally Friendly: RoHS compliance ensures adherence to environmental regulations.

Additional Details

The STS2302A typically comes in a surface-mount package. Key specifications include drain-source voltage (VDS), gate-source voltage (VGS), continuous drain current (ID), and operating temperature range. The exact values for these parameters depend on the specific datasheet revision. It's crucial to consult the latest datasheet from SamHop for precise electrical characteristics, thermal resistance, and package dimensions before using this MOSFET in any design. The gate threshold voltage is also a critical parameter for proper circuit design.
