Category Transformers - Pulse Transformers
Mfr SCHOTT CORPORATION
Package Tape & Reel (TR)Cut Tape (CT)
Product Status Discontinued
Transformer Type T1/E1 (Quad)
Inductance 1.2mH
Mounting Type Surface Mount
Size / Dimension 1.000" L x 0.300" W (25.40mm x 7.62mm)
Height - Seated (Max) 0.290" (7.37mm)
Standard Package 500 pcs
Moisture Sensitivity Level (MSL) Not Applicable
ECCN EAR99
HTSUS 8504.31.2000
Win Source Part Number 545637-37533
Ultra Librarian 3D Model Ultra Librarian 37533 CAD Model

Description

The 545637-37533 is a pulse transformer designed for use in transformers. It is suitable for T1/E1 (Quad) applications and is manufactured by SCHOTT CORPORATION.

  • This product is available: in tape & reel and cut tape packaging, with a size dimension of 1.000" L x 0.300" W (25.40mm x 7.62mm).
  • It has an inductance: of 1.2mH and a maximum seated height of 0.290" (7.37mm).
  • The standard package: for this product is 500 pieces.
  • It is designed: for surface mount mounting and does not have a specified operating temperature range.
  • The ECCN classification: for this product is EAR99, indicating that it is not subject to export controls.
  • The HTSUS code: for this product is 8504.31.2000.
  • The 545637-37533 is a discontinued product: and its moisture sensitivity level is not applicable.
