PC355NJ0000F Sharp Microelectronics
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 600% @ 1mA
Rise and Fall Time 60μs, 53μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 35V
Channel Output Current 80mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 1V
Temperature Range - Operating -30°C to 100°C
Mounting SMD (SMT)
Case / Package 4-Mini-Flat
Win Source Part Number 026417-PC355NJ0000F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name PC355
Introduction Date November 20, 2003
ECCN EAR99
Country of Origin China, Indonesia, Japan
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian PC355NJ0000F CAD Model

Description

This electronic component is a Sharp Microelectronics product with a Win Source Part Number of 026417-PC355NJ0000F.

  • Isolator Output Type: Darlington
  • Input Type: DC
  • Maximum Forward Voltage: 1.2V
  • Isolation Voltage: 3750Vrms
  • Number of Channels: 1
  • Vce Saturation (Max): 1V
  • Family Name: PC355
  • Case/Package: 4-mini-flat
  • Supply and Demand Status: sufficient
