PC410L Sharp Microelectronics PC410L real image4459 PC410L label picture PC410L real image
Same model may have multiple batches, images only for reference.
PC410L Sharp Microelectronics PC410L real image4459 PC410L label picture PC410L real image
PC410L Sharp Microelectronics PC410L real image4459 PC410L label picture PC410L real image
Same model may have multiple batches, images only for reference.

PC410L

Part No PC410L
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPEN COLL 5MFP
Datasheet
PC410L Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Open Collector
Channel Output Current 50mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Max) 75ns, 75ns
Rise and Fall Time 10ns, 20ns
Forward Voltage 1.6V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 5-MFP
Win Source Part Number 091950-PC410L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PC410L CAD Model

Description

The Sharp Microelectronics PC410L is a high-popularity electronic component used in various electronic devices.

  • Lifecycle Status: Obsolete
  • Supply and Demand Status: Limited
  • Package: 5-MFP
  • Common Mode Transient Immunity: 10kV/μs
  • Channel Output Current: 50mA
  • Continuous Forward Current: 20mA
  • Operating Temperature: -40°C to 85°C
