Products specifications Report Issue?

Category Resistors - Chip Resistor - Surface Mount
Mfr Stackpole Electronics Inc.
Series RMCF
Package Tape & Reel
Product Status Active
Resistance 100 kOhms
Tolerance ±5%
Power (Watts) 0.063W, 1/16W
Composition Thick Film
Features Automotive AEC-Q200
Temperature Coefficient ±100ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Package / Case 0402 (1005 Metric)
Supplier Device Package 0402
Ratings AEC-Q200
Size / Dimension 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) 0.016" (0.40mm)
Number of Terminations 2
Standard Package 10,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.21.0030
Win Source Part Number 843697-RMCF0402JT100K
Ultra Librarian 3D Model Ultra Librarian RMCF0402JT100K CAD Model

Description

The RMCF0402JT100K is a chip resistor for surface mount applications.

  • Resistance: It has a resistance of 100 kOhms.
  • Power Rating: and a power rating of 0.063W (1/16W).
  • Tolerance: The tolerance is ±5%.
  • Temperature Coefficient: and the temperature coefficient is ±100ppm/°C.
  • Series: This resistor is part of the RMCF series from Stackpole Electronics Inc.
  • Features: It features automotive AEC-Q200 ratings.
  • Size/Dimension: The size/dimension of the resistor is 0.039" L x 0.020" W (1.00mm x 0.50mm).
  • Height: with a height of 0.016" (0.40mm) when seated.
  • Package: It comes in a tape & reel package.
  • Standard Package Quantity: with a standard package quantity of 10,000 pcs.
  • Operating Temperature Range: The operating temperature range is -55°C to 155°C.
  • ECCN Code: The ECCN code for this product is EAR99.
