RSMF5JB510R Real Image
Same model may have multiple batches, images only for reference.

RSMF5JB510R

Part No RSMF5JB510R
Manufacturer Stackpole Electronics Inc.
Catalog Through Hole Resistors
Description RES 510 OHM 5% 5W AXIAL / 510 Ohms ±5% 5W Through Hole Resistor Axial Flame Proof, Safety Metal Oxide Film
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors>Through Hole Resistors
Mfr Stackpole Electronics Inc.
Series RSMF
Package Bulk
Resistance 510 Ohms
Tolerance ±5%
Power (Watts) 5W
Composition Metal Oxide Film
Features Flame Proof, Safety
Temperature Coefficient ±200ppm/°C
Temperature Range - Operating -55°C ~ 235°C
Package / Case Axial
Supplier Device Package Axial
Size / Dimension 0.236" Dia x 0.689" L (6.00mm x 17.50mm)
Height - Seated (Max) -
Number of Terminations 2
Failure Rate -
Moisture Sensitivity Level (MSL) Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.21.0090
Standard Package 200 pcs
Win Source Part Number 1383466-RSMF5JB510R
Ultra Librarian 3D Model Ultra Librarian RSMF5JB510R CAD Model

Description

The RSMF5JB510R Through Hole Resistor is a high-quality component designed for various electronic applications. It features a flame-proof and safety design, ensuring reliable and safe operation.

  • Power Rating: 5W
  • Resistance Value: 510 Ohms
  • Tolerance: ±5%
  • Material: Metal Oxide Film
  • Mounting Type: Axial
  • Package: Bulk
  • Operating Temperature: -55°C to 235°C
