Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 2
STAND-OFF Voltage (Vwm) 5.25V
Minimum Breakdown Voltage 6.1V
Power Dissipation - Pd 300W
Applications General Purpose
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 015715-ESDA6V1L
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Industrial
Family Name ESDA6V1L
Introduction Date March 24, 2000
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian ESDA6V1L CAD Model

Description

Overview of the ESDA6V1L Transil™ ESD Protector

The ESDA6V1L is a state-of-the-art Transil™ ESD protection device manufactured by STMicroelectronics, designed to safeguard sensitive electronic equipment from electrostatic discharges (ESD). This robust component is specifically engineered to protect voltage-sensitive devices that are prone to damage when exposed to transient voltage spikes.

Key Features

  • Low Clamping Voltage: The ESDA6V1L offers an exceptionally low clamping voltage, providing superior protection for sensitive circuits against ESD without compromising the signal integrity.
  • High ESD Protection: It can withstand ESD discharges up to 30 kV (air discharge) and 30 kV (contact discharge) as per the IEC 61000-4-2 standard, ensuring the safety of your electronic components during handling and operation.
  • Single Line Protection: This device is capable of protecting one data or power line, making it an ideal choice for targeted applications.
  • Low Leakage Current: The ESDA6V1L exhibits a very low leakage current, thereby reducing power consumption and increasing the efficiency of the overall system.
  • SOT-23 Package: Its small form factor SOT-23 package makes it suitable for high-density board layouts, allowing for easier design integration in compact electronic assemblies.

Applications

The ESDA6V1L is versatile and can be used across various applications where ESD protection is crucial. Some common applications include:

  • Mobile phones and other portable devices
  • Computers and peripherals
  • Networking and telecommunications systems
  • Industrial controls
  • Medical equipment

Advantages

By incorporating the ESDA6V1L into your design, you benefit from the enhanced reliability and durability of your electronic devices. It ensures longevity of sensitive components and reduces the risk of failure due to ESD events. Moreover, its compatibility with high-speed data lines and power buses makes it a versatile solution for a wide range of electronic applications.

STMicroelectronics' commitment to quality and performance is evident in the ESDA6V1L, making it a top choice for designers looking to enhance the ESD robustness of their electronic products.
