Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer STMicroelectronics
Series VIPower
Main Purpose Power Management, High Side Driver (Internal FET)
Utilized IC / Part VN5E050AJ
Primary Attributes 1-Channel (Single)
Supplied Contents Board(s)
Win Source Part Number 799127-EV-VN5E050AJ
Popularity Medium
Supply and Demand Status Limited
Family Name EV-VN5E050AJ
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian EV-VN5E050AJ CAD Model

Description

STMicroelectronics EV-VN5E050AJ Evaluation Board

The EV-VN5E050AJ from STMicroelectronics is a state-of-the-art evaluation board designed specifically for automotive applications. This product showcases the capabilities of the VN5E050AJ high-side driver, which is an integral component in the realm of power management and control in modern vehicles. The evaluation board serves as a robust platform for testing and developing applications involving this high-side driver.

Key Features

  • High-Side Driver Integration: The VN5E050AJ high-side driver is the centerpiece of the evaluation board, featuring a single channel with a 50 mΩ typical RDS(on) at 25°C. This ensures efficient power control and distribution.
  • Load Current Capability: The board is capable of handling significant load currents, making it suitable for a variety of automotive applications, including but not limited to driving resistive, inductive, and capacitive loads.
  • Advanced Diagnostics: Equipped with comprehensive diagnostic functions, the EV-VN5E050AJ can detect and report both open-load conditions in the off-state and feedback of the load current while on.
  • Over-Temperature Protection: Safety is paramount in automotive applications, and this evaluation board includes over-temperature shutdown with auto-restart to prevent damage from overheating.
  • Undervoltage Shutdown: To safeguard the system against power supply fluctuations, the board features undervoltage shutdown, ensuring stable operation under varying conditions.

Applications

The EV-VN5E050AJ is designed to cater to a wide range of automotive applications, including but not limited to:

  • Lamp driving
  • Heating resistors
  • Motor driving
  • Automotive interior or exterior lighting

Design and Development Support

STMicroelectronics provides comprehensive support for the design and development process with the EV-VN5E050AJ evaluation board. Engineers can leverage this platform to streamline the prototyping phase, ensuring rapid development and deployment of their automotive solutions. The evaluation board is also compatible with a variety of microcontroller units (MCUs), making it a versatile tool for integration into a wide array of automotive systems.

Whether for R&D or educational purposes, the EV-VN5E050AJ evaluation board from STMicroelectronics is an excellent choice for professionals looking to explore the capabilities of high-side drivers in automotive applications.
