Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr Analog Devices Inc./Maxim Integrated
Package Box
Type Power Management
Function High Side Driver (Internal FET)
Utilized IC / Part MAX14913
Primary Attributes 8-Channel (Octal)
Supplied Contents Board(s)
Secondary Attributes On-Board LEDs
Base Product Number MAX14913
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Standard Package 1
Win Source Part Number 1033120-MAX14913EVKIT#
Ultra Librarian 3D Model Ultra Librarian MAX14913EVKIT# CAD Model

Description

Maxim Integrated MAX14913EVKIT# Evaluation Kit

The MAX14913EVKIT# from Maxim Integrated is a comprehensive evaluation kit designed to showcase the features and capabilities of the MAX14913 octal high-side switch and digital input. This evaluation kit provides an easy-to-use platform for testing and prototyping applications that require multiple high-side switches with robust protection features.

Key Features of the MAX14913EVKIT#

  • Octal High-Side Switch: The kit features the MAX14913, which can drive up to eight high-side switches, making it ideal for industrial automation and control systems.
  • Integrated Digital Input: Each switch channel can also be configured as a digital input, providing versatility in interfacing with various sensors and input devices.
  • High Voltage Operation: The MAX14913 is capable of operating at voltages up to 40V, allowing the evaluation kit to handle a wide range of industrial applications.
  • Robust Protection Mechanisms: The device includes features such as overcurrent protection, thermal shutdown, and fault indication, ensuring reliable operation under adverse conditions.
  • Flexible Control Interface: The kit supports both SPI and parallel interface options for controlling the high-side switches or reading the digital inputs.
  • LED Indicators: On-board LEDs provide visual feedback for switch status, input status, and fault conditions, aiding in quick diagnostics and monitoring.
  • Provision for External Loads: The evaluation board includes terminal blocks for connecting external loads, making it easy to set up real-world testing scenarios.

Applications

The MAX14913EVKIT# is suitable for a variety of applications, including:

  • Programmable Logic Controllers (PLCs)
  • Industrial I/O Modules
  • Factory Automation Systems
  • Building Automation

The evaluation kit comes with everything needed to begin testing, including the evaluation board, a USB cable, and comprehensive documentation. The MAX14913EVKIT# is an indispensable tool for engineers and developers looking to explore the functionalities of the MAX14913 high-side switch and digital input for their industrial control solutions.
