Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer STMicroelectronics
Series VIPower
Main Purpose Power Management, High Side Driver (Internal FET)
Utilized IC / Part VN7040AS
Primary Attributes 1-Channel (Single)
Supplied Contents Board(s)
Win Source Part Number 799132-EV-VN7040AS
Popularity Medium
Supply and Demand Status Limited
Family Name EV-VN7040AS
ECCN EAR99
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian EV-VN7040AS CAD Model

Description

The EV-VN7040AS from STMicroelectronics is an evaluation board designed for the VN7040AS high-side driver integrated circuit. This evaluation board offers engineers and developers a convenient and efficient platform for testing the capabilities and performance of the VN7040AS component in various applications.

The VN7040AS is an advanced high-side driver manufactured by STMicroelectronics, featuring an integrated vertical current flow power MOSFET and intelligent circuitry for driving resistive, inductive, and capacitive loads. This component is particularly well-suited for automotive applications, as well as industrial automation, smart home systems, and other high-reliability environments where efficient power management is critical.

The EV-VN7040AS evaluation board simplifies the development process by providing all the necessary hardware to interface with the VN7040AS chip. It includes features such as diagnostic functions, a robust design with protection against overtemperature, overload, and short circuits, as well as under-voltage shutdown with auto-restart and hysteresis.

With the evaluation board, users can easily connect to a microcontroller or other control unit to send commands and receive feedback from the VN7040AS. This allows for the thorough testing of the device's functionalities, such as its fast demagnetization of inductive loads, clamping of turn-off transient voltages, and compliance with stringent automotive standards for electromagnetic compatibility (EMC).

The board is designed with user-friendliness in mind, featuring accessible test points, clear labeling, and a comprehensive user manual that guides users through the setup and testing processes. This makes the EV-VN7040AS an invaluable tool for both experienced engineers and those new to power management design.

Overall, the EV-VN7040AS evaluation board is an essential resource for anyone looking to explore the full potential of the VN7040AS high-side driver and to accelerate the development of applications requiring reliable and efficient power switching solutions.
