Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Purpose Set(Preset) and Reset
Type D-Type
Output Type Differential
Number of Elements 2
Number of Bits per Element 1
Max Frequency 67MHz
Max Propagation Delay @ V, Max CL 26ns @ 6V, 50pF
Trigger Type Positive Edge
Current - Output High, Low 5.2mA, 5.2mA
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent 2μA
Input Capacitance 5pF
Temperature Range - Operating -55°C to 125°C (TA)
Mounting SMD (SMT)
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 107728-M74HC74RM13TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name M74HC74
Introduction Date August 15, 1995
ECCN EAR99
Country of Origin China, Morocco
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian M74HC74RM13TR CAD Model

Description

The M74HC74RM13TR is a high-speed CMOS dual D-type flip-flop integrated circuit, brought to you by the renowned semiconductor manufacturer, STMicroelectronics. This device is specifically designed to operate in a wide range of applications, from automation to consumer electronics, offering both reliability and performance. The M74HC74RM13TR is part of the HC family, which means it has the ability to interface with TTL levels while providing a much lower power consumption, making it an ideal choice for battery-operated devices.

Key Features

  • Logic Type: Dual D-type flip-flop with set and reset
  • Output Type: Differential
  • High-Speed Performance: Symmetrical output impedance, high noise immunity, and low power dissipation
  • Operating Voltage Range: 2 V to 6 V, accommodating a variety of logic level requirements
  • Temperature Range: -55°C to 125°C, ensuring reliable operation under extreme conditions
  • Package: Supplied in a thin shrink small outline package (TSSOP), specifically the 14-lead TSSOP
  • Compliance: Meets JEDEC standard no. 7A requirements
  • ESD Performance: HBM: 2 kV, MM: 200 V, ensuring robustness for handling and assembly processes

Applications

The M74HC74RM13TR is incredibly versatile and can be used in a wide array of applications. Some of the typical applications include:

  • Automotive industry for control units and electronics
  • Communication devices where data retention is critical
  • Consumer electronics, including gaming consoles and personal computers
  • Industrial automation systems for process control
  • Medical devices that require high reliability and precision

Quality and Environmental Data

STMicroelectronics is committed to providing environmentally friendly products. The M74HC74RM13TR is compliant with the RoHS directive, which restricts the use of certain hazardous substances in electrical and electronic equipment. Additionally, the product is fully compliant with the REACH regulation, ensuring safety for both consumers and the environment.
