Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer STMicroelectronics
Series VIPower
Main Purpose Power Management, High Side Driver (Internal FET)
Utilized IC / Part VND7140AJ
Primary Attributes 2-Channel (Dual)
Supplied Contents Board(s)
Win Source Part Number 772358-EV-VND7140AJ
Popularity Medium
Supply and Demand Status Limited
Family Name EV-VND7140AJ
ECCN EAR99
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian EV-VND7140AJ CAD Model

Description

STMicroelectronics EV-VND7140AJ Product Overview

The EV-VND7140AJ from STMicroelectronics is a state-of-the-art automotive-grade double-channel high-side driver integrated circuit (IC) designed to drive a wide range of loads with advanced power management capabilities. This product is part of the VIPower™ M0-7 series, which is renowned for its robustness and reliability, making it an ideal choice for automotive applications where performance and durability are critical.

Key Features

  • High-Side Switch Type: The EV-VND7140AJ is a high-side driver, meaning it connects the load to the power supply and controls it by applying or removing the ground.
  • Current Rating: It can handle continuous current up to 25A, making it suitable for a variety of high-power applications.
  • MultiSense Analog Feedback: The device provides precise feedback on critical parameters such as load current, voltage, and temperature, enabling sophisticated diagnostics and control.
  • Advanced Protection: The IC includes protections against over-temperature, overload, and short circuits to the battery or ground, ensuring the safety and longevity of the application.
  • Compliance: It is fully compliant with automotive standards, including those for electromagnetic compatibility (EMC).

Applications

The EV-VND7140AJ is versatile and can be used in a range of automotive applications, such as:

  • Headlight and rear light driving
  • Heating, Ventilation, and Air Conditioning (HVAC) systems
  • Engine and transmission control units
  • Electric power steering
  • Active suspension and ABS

Development Support

For ease of development and testing, STMicroelectronics provides comprehensive support for the EV-VND7140AJ, including evaluation boards and detailed technical documentation. Engineers can rapidly prototype and test their designs, significantly reducing time-to-market for automotive systems.

With its robust design, advanced features, and strong support, the EV-VND7140AJ is a reliable and efficient solution for driving high-power loads in automotive environments. It embodies STMicroelectronics' commitment to delivering high-performance, automotive-grade ICs that meet the stringent demands of the industry.
