Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Power Distribution Switches, Load Drivers
Mfr STMicroelectronics
Package Tray
Product Status Active
Switch Type Relay, Solenoid Driver
Number of Outputs 8
Output Configuration High Side
Interface Parallel
Voltage - Load 10.5V ~ 36V
Current - Output (Max) 700mA
Rds On (Typ) 120mOhm
Features Auto Restart, Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage, UVLO
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 32-TFQFPN (11x9)
Package / Case 32-TQFN Exposed Pad
Base Product Number ISO8200
Standard Package 1,260 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 851198-ISO8200BQ
Ultra Librarian 3D Model Ultra Librarian ISO8200BQ CAD Model

Description

The ISO8200BQ from STMicroelectronics is a state-of-the-art, octal high-side smart power solid-state relay designed to address the needs of modern industrial automation and control applications. This robust component integrates eight high-side drivers into a single compact QFN package, providing a space-efficient solution for driving a wide range of loads, including resistive, capacitive, and inductive loads.

With an impressive voltage range of 8 to 60 V, the ISO8200BQ is capable of delivering outstanding performance across various supply conditions. Each channel of the ISO8200BQ can handle a continuous current of up to 0.7 A, making it suitable for driving moderate loads. The device also features an over-temperature protection mechanism that ensures safe operation by shutting down the output if the junction temperature exceeds the preset threshold.

The ISO8200BQ is designed with built-in diagnostic features, including open-load detection in off-state, shorted load detection, and over-temperature indication. These diagnostics are accessible through a serial peripheral interface (SPI), which also enables control and feedback for each individual channel. This level of control and monitoring ensures high reliability and simplifies system design by reducing the need for additional components.

One of the standout features of the ISO8200BQ is its galvanic isolation between the logic and power stages, which provides enhanced safety and protection for sensitive microcontroller circuits. The device also boasts a low power consumption in standby mode, making it an energy-efficient choice for power-conscious designs.

The ISO8200BQ is encapsulated in a QFN-32 package, which not only conserves board space but also enhances thermal performance. This package is optimized for efficient heat dissipation, ensuring reliable operation even in high-power applications. With its robust design and comprehensive feature set, the ISO8200BQ is an ideal solution for driving solenoids, lamps, and other actuators in industrial automation, PLCs, and many other demanding applications.
