Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 35V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 2V @ 1A (Typ)
Output Current 1.5A
Operating Supply Current 8mA
PSRR 62dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 2V @ 1A
Mounting SMD (SMT)
Case / Package D-Pak
Win Source Part Number 018343-L7805CDT-TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name L7805C
Introduction Date June 21, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian L7805CDT-TR CAD Model

Description

L7805CDT-TR from STMicroelectronics is a linear voltage regulator used where designers need a straightforward fixed-voltage power rail in embedded, industrial, and general-purpose electronic systems. Devices in this category are commonly selected for post-regulation, local power conditioning, and supporting logic, control, or analog circuitry where low design complexity is important. Engineers often choose this type of regulator for proven topology, broad ecosystem familiarity, and easy integration into legacy or cost-sensitive designs. Typical use cases include control boards, instrumentation, consumer appliances, and auxiliary regulated rails in larger systems. The current lifecycle status for L7805CDT-TR is information not available, so teams supporting long-life products should confirm manufacturer status before locking it into new designs or making major procurement commitments. RoHS compliance information is also not available in the provided data. Engineers and sourcing teams should verify the latest environmental compliance, material declarations, and datasheet details directly with STMicroelectronics or authorized distribution channels.
