Products specifications

Categories Circuit Protection
Estimated Pruduction Lead Time 13 Weeks
Features Clamp Ipp Tvs Diode
Manufacturer STMicroelectronics
Series Automotive, AEC-Q101, LDP01Y, TRANSIL™
Package Reel - TR
Family Name LDP01
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number 497-15292-6, 497-15292-1, 497-15292-2, -497-15292-6, -497-15292-2, -497-15292-1
Quantity per package 1000
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 876956-LDP01-26AY
Ultra Librarian 3D Model Ultra Librarian LDP01-26AY CAD Model

Description

The LDP01-26AY is a state-of-the-art protection device manufactured by STMicroelectronics, designed to safeguard automotive ECUs and other sensitive electronics from the destructive effects of load dump pulses. This product is an integral component in the quest to enhance the reliability and durability of automotive electronics.

Key Features

  • Load Dump Pulse Protection: The LDP01-26AY is specifically tailored to protect against load dump pulses, which are significant surges in voltage that occur when a battery connection is suddenly disconnected while the alternator is charging.
  • ISO 7637-2 and ISO 16750-2 Compliance: It meets the stringent requirements of the ISO 7637-2 and ISO 16750-2 standards for transient protection, ensuring compatibility with automotive regulatory demands.
  • High Surge Capability: With its robust surge capability, the LDP01-26AY can handle extreme transient conditions, ensuring that connected devices remain safe and operational.
  • Low Clamping Voltage: The device features a low clamping voltage, which is crucial for protecting sensitive circuitry from voltage spikes without hindering normal operation.
  • Wide Operating Temperature Range: The device is designed to operate effectively over a broad temperature range, making it suitable for the harsh environments typically found in automotive applications.

Applications

The LDP01-26AY is ideal for use in a variety of automotive applications, including:

  • ECU protection
  • Powertrain systems
  • Infotainment systems
  • Advanced driver-assistance systems (ADAS)
  • Body and chassis electronics

Technical Specifications

With a commitment to quality and performance, STMicroelectronics ensures that the LDP01-26AY meets the highest technical specifications. The device is packaged in a compact, surface-mount design, making it easy to integrate into various electronic assemblies.

For detailed technical data, reference sheets, and application notes, customers are encouraged to visit the STMicroelectronics website or contact their sales and technical support team.
