Products specifications

Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management
ECCN EAR99
Introduction Date June 21, 2004
Family Name LF50AB
Win Source Part Number 002509-LF50ABDT-TR
Case / Package D-Pak
Mounting SMD (SMT)
Voltage - Dropout (Typical) 0.4V @ 500mA
Output Voltage 5V
Regulator Topology Positive Fixed
Temperature Range - Operating -40°C to 125°C
Control Protection Features Over Current, Over Temperature
PSRR 76dB to 60dB (120Hz to 10kHz)
Operating Supply Current 1mA to 12mA
Output Current 500mA
Dropout Voltage-Max 0.7V @ 500mA
Nominal Output Voltage (Min/Fixed) 5V
Maximum Input Voltage 16V
Number of Regulators 1
Output Type Fixed
Status Active
Packaging Reel - TR
Manufacturer STMicroelectronics
Categories Integrated Circuits
Ultra Librarian 3D Model Ultra Librarian LF50ABDT-TR CAD Model

Description

The LF50ABDT-TR from STMicroelectronics is a robust, high-performance low dropout (LDO) voltage regulator designed for a wide range of applications. This device offers a stable and reliable 5V output, making it an ideal choice for sensitive electronics that require a consistent power supply. The LF50ABDT-TR is part of STMicroelectronics' LFxx series and is specifically tailored to deliver low noise and low dropout performance.

With an output current capability of up to 500mA, the LF50ABDT-TR is suitable for powering microcontrollers, sensors, and other digital and analog ICs. The regulator's low dropout voltage ensures efficient operation even when the input voltage is very close to the output voltage, thereby minimizing power loss and improving overall system efficiency.

The LF50ABDT-TR is designed with thermal shutdown and current limiting features, which protect the device and the application circuit from damage due to overheating and overcurrent conditions. These built-in protection mechanisms contribute to the long-term reliability and stability of the regulator, making it a trusted choice for critical applications.

This voltage regulator comes in a TO-252 (DPAK) package, which offers a compact footprint while still providing excellent thermal performance. The surface-mount design of the LF50ABDT-TR allows for efficient assembly in automated manufacturing processes, making it suitable for high-volume production.

Key features of the LF50ABDT-TR include:

  • Output voltage: 5V
  • Output current: up to 500mA
  • Low dropout voltage
  • Thermal shutdown and current limiting protection
  • TO-252 (DPAK) package for efficient heat dissipation

Whether you're designing consumer electronics, automotive systems, or industrial controls, the LF50ABDT-TR voltage regulator from STMicroelectronics provides the performance and reliability needed to ensure stable operation in a variety of challenging environments.
