Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type General Purpose
Number of Elements 4
Output Type CMOS, DTL, ECL, MOS, Open-Collector, TTL
Supply Voltage - Operating 2 V to 32 V, ±1 V to 16 V
Voltage - Input Offset (Max) 2mV @ 30V
Current - Input Bias (Max) 0.1μA @ 5V
Current - Output (Typ) 16mA @ 5V
Current - Quiescent (Max) 2.5mA
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SO
Win Source Part Number 019107-LM339ADT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM339ADT CAD Model

Description

The LM339ADT from STMicroelectronics is a high-performance quad differential comparator designed to provide a precise voltage comparison across a wide range of applications. Housed in a compact SO-14 package, this integrated circuit is optimized for low power consumption while maintaining a high level of accuracy and reliability.

Key Features

  • Wide Voltage Range: The LM339ADT operates from a single power supply over a wide range of voltages, or can be used with a dual power supply, making it versatile for various circuit configurations.
  • Low Power Consumption: This comparator is designed for low power operation, which is crucial for battery-powered and portable devices, ensuring energy efficiency without compromising performance.
  • Open Collector Outputs: The open collector output configuration allows for wired-AND connections and is capable of driving loads connected to a higher voltage than the comparator's supply.
  • Input Offset Voltage: It features a low input offset voltage, which enhances the accuracy of the device by minimizing the differential voltage required for switching.
  • Wide Operating Temperature Range: The LM339ADT is designed to operate over a temperature range of -40°C to +125°C, making it suitable for industrial and automotive environments.

Applications

The LM339ADT is widely used in a variety of electronic circuits. Its applications include, but are not limited to:

  • Limit comparators
  • Simple analog to digital converters
  • Voltage monitoring
  • Battery chargers
  • Time delay generators
  • Window detectors

Reliability and Quality

STMicroelectronics is well-known for its commitment to quality and reliability, and the LM339ADT is no exception. Each device undergoes rigorous testing to ensure it meets the high standards expected for industrial and automotive grade components. The LM339ADT is RoHS compliant and is designed to meet the requirements of the most demanding applications.

With its precise voltage comparison capabilities and robust design, the LM339ADT is an ideal choice for designers looking for a reliable comparator solution.
