Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type General Purpose
Number of Elements 2
Output Type CMOS, DTL, ECL, MOS, Open-Collector, TTL
Supply Voltage - Operating 2 V to 36 V, ±1 V to 18 V
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 18mA @ 5V
Current - Quiescent (Max) 2.5mA
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 019212-LM393DT
Family Name LM393
Introduction Date July 02, 2002
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Sensing & Instrumentation
Ultra Librarian 3D Model Ultra Librarian LM393DT CAD Model

Description

Overview of the LM393DT Dual Differential Comparator

The LM393DT, manufactured by STMicroelectronics, is a low-power dual voltage comparator that is widely used in electronic applications for comparing two voltages or currents and determining the larger value. This device is designed to operate from a single power supply over a wide range of voltages, or from dual supplies for systems that require a bipolar input voltage capability.

Key Features

  • Wide Supply Range: The LM393DT can operate from a single supply voltage ranging from 2V to 36V, or dual supplies of ±1V to ±18V, making it versatile for various electronic circuits.
  • Low Supply Current: With a typical supply current specification of 0.4 mA, this comparator is suitable for battery-powered and portable devices due to its energy-efficient design.
  • Dual Comparators: The device includes two independent voltage comparators that can be used in a variety of configurations, such as window comparators or time delay circuits.
  • Output Compatibility: The open-collector outputs of the LM393DT allow for direct interfacing with TTL, MOS, and CMOS logic systems without the need for external components.
  • Input Offset Voltage: Typically, the input offset voltage is 5 mV, which is adequate for many applications requiring a basic level of precision.
  • Wide Operating Temperature Range: The device can function over a temperature range of 0°C to 70°C, ensuring reliable performance across various environmental conditions.

Applications

The LM393DT is commonly used in several applications, including:

  • Limit comparators
  • Voltage and current monitoring
  • Signal waveform discrimination
  • Simple analog to digital converters
  • Relay drivers
  • Precision timing circuits
  • Battery chargers

With its dual comparator design, the LM393DT from STMicroelectronics provides a reliable and cost-effective solution for a multitude of electronic circuits that require voltage or current comparison. Its low power consumption and wide operating voltage range make it a go-to choice for designers looking for a standard comparator for their applications.
