Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Obsolete(EOL)
Memory Format FLASH
Technology FLASH
Memory Size 1Mb (128K x 8)
Access Time 90ns
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 52-PQFP (10x10)
Win Source Part Number 084953-PSD813F2A-90MI
Family Name PSD813F2
Introduction Date October 15, 1999
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PSD813F2A-90MI CAD Model

Description

STMicroelectronics PSD813F2A-90MI Flash In-System Programmable (ISP) Peripherals

The PSD813F2A-90MI is a sophisticated Flash In-System Programmable (ISP) Peripheral from STMicroelectronics, designed to cater to a wide range of embedded control systems. This device integrates a wealth of features to provide a versatile and efficient solution for system-level management and control in various applications.

At the heart of the PSD813F2A-90MI is a high-density CMOS Flash memory, offering 90ns access time, which ensures swift data retrieval and processing speeds, making it ideal for high-performance systems. The Flash memory is complemented by additional EEPROM for data storage, which is particularly useful for storing configuration settings and parameters that need to be preserved across power cycles.

One of the key advantages of this product is its In-System Programmability. Users can update the firmware and data stored in the device without removing it from the circuit board, significantly simplifying the upgrade process and reducing downtime. This feature is invaluable for applications where the system software must evolve over time to accommodate new features or improvements.

The PSD813F2A-90MI also features an array of programmable logic, including macrocells and interconnects, which allow for the customization of logic functions tailored to specific application requirements. This level of programmability extends the device’s utility and can lead to cost savings by reducing the number of discrete components needed on the PCB.

Connectivity is another strong suit of the PSD813F2A-90MI, which includes an 8-bit microcontroller interface that is compatible with the majority of the popular 8-bit microcontrollers on the market. This ensures that the device can be easily integrated into existing designs, providing a seamless upgrade path for enhancing system capabilities.

In summary, the PSD813F2A-90MI from STMicroelectronics is a powerful and flexible ISP peripheral that is well-suited for a variety of embedded control applications. Its combination of Flash memory, EEPROM, programmable logic, and easy connectivity makes it a valuable component for system designers looking to create sophisticated, reliable, and upgradable products.
