Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 28.2V
Minimum Breakdown Voltage 31.4V
Max Clamping Voltage 59V
Peak Pulse Current(Ippm) 169A (8/20μs)
Power Dissipation - Pd 1500W (1.5kW)
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMC
Win Source Part Number 028948-SM15T33A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SM15T33A CAD Model

Description

The SM15T33A is a robust transient voltage suppressor (TVS) diode from STMicroelectronics, designed to protect sensitive electronic equipment from voltage transients induced by system inductance, lightning, and other transient voltage events. This TVS diode is particularly suitable for applications where high reliability and surge capability are critical for system protection.

Key Features

  • Stand-off Voltage: 33V - This device is designed to protect equipment operating at this nominal voltage level.
  • Peak Pulse Power Dissipation: 1500W (10/1000μs) - The SM15T33A can absorb high levels of transient power, ensuring protection against surges.
  • Low Clamping Voltage: The low clamping voltage ensures that the protected component sees a voltage within its tolerance during transient events.
  • Uni-directional Device: It is designed to protect against transients in one direction, making it ideal for DC applications.
  • Junction Passivation: Optimized for increased reliability and robustness against thermal and mechanical stresses.

Applications

The SM15T33A is versatile and can be used in a wide range of applications, including:

  • Power supply lines
  • Industrial systems
  • Telecommunication devices
  • Automotive electronics
  • Consumer electronics

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The SM15T33A is manufactured in ISO-certified facilities, ensuring that each device meets the stringent requirements necessary for industrial and automotive applications. The device is also RoHS and REACH compliant, reflecting STMicroelectronics' dedication to environmental responsibility.

Package and Availability

The SM15T33A is available in an SMB (DO-214AA) surface-mount package which is designed to optimize board space and simplify the manufacturing process. Its package is compatible with standard SMT assembly lines, allowing for easy integration into existing designs. Check with STMicroelectronics or authorized distributors for availability and bulk pricing options.
