Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 12V
Minimum Breakdown Voltage 13.3V
Max Clamping Voltage 25.3V
Peak Pulse Current(Ippm) 91A (8/20μs)
Power Dissipation - Pd 400W
Applications General Purpose
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SMA (DO-214AC)
Win Source Part Number 103679-SMAJ12CA-TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial, Communications & Networking
Family Name SMAJ12CA
Introduction Date August 02, 2004
ECCN EAR99
Country of Origin China, Morocco
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SMAJ12CA-TR CAD Model

Description

STMicroelectronics SMAJ12CA-TR Transient Voltage Suppressor

The SMAJ12CA-TR from STMicroelectronics is a robust transient voltage suppressor (TVS) diode designed to protect sensitive electronic equipment from voltage transients induced by system-level events such as load dump, lightning, and electrostatic discharge (ESD). This device is particularly suitable for the protection of voltage-sensitive components that require a high level of reliability and performance to comply with rigorous industrial standards.

Key Features

  • Stand-off Voltage: The SMAJ12CA-TR has a stand-off voltage of 12V, which makes it an ideal choice for protecting 12V systems.
  • Peak Pulse Power: It can handle peak pulse power dissipation of 400W (10/1000μs), providing a high level of protection against surge transients.
  • Bi-directional Protection: As a bi-directional TVS, the SMAJ12CA-TR can protect circuits from surges that may occur in both directions along the protected line.
  • Low Clamping Voltage: The device features a low clamping voltage, ensuring that the protected component is exposed to minimal stress during surge events.
  • Fast Response Time: The TVS diode boasts an exceptionally fast response time to transient events, typically in the order of picoseconds, providing immediate protection upon detection of a surge.
  • DO-214AC (SMA) Package: Encased in a compact DO-214AC (SMA) package, the SMAJ12CA-TR is designed for space-constrained applications while offering excellent thermal and electrical capabilities.

Applications

The SMAJ12CA-TR is versatile and can be used across various applications where transient voltage protection is critical. Common applications include:

  • Power supply lines
  • Communication systems
  • Automotive electronics
  • Industrial controls
  • Consumer electronics

With its combination of features, the SMAJ12CA-TR is an excellent choice for designers looking for a reliable and high-performance solution to safeguard their electronic systems. STMicroelectronics' commitment to quality ensures that the SMAJ12CA-TR TVS diode meets the stringent requirements for surge protection in a wide range of applications.
