Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.7V
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 0.8V
Maximum Output Voltage 5.22V
Output Current 2A
Frequency - Switching 1.5MHz
Synchronous Rectifier Yes
Temperature Range - Operating -30°C to 85°C (TJ)
Mounting SMD (SMT)
Case / Package 6-DFN (3x3)
Win Source Part Number 117117-ST1S09PUR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ST1S09PUR CAD Model

Description

The ST1S09PUR is a highly efficient, single-channel, non-synchronous step-down DC-DC converter designed and manufactured by STMicroelectronics. This compact and robust integrated circuit is ideal for portable applications where space is at a premium and power efficiency is paramount.

With an input voltage range of 2.5V to 5.5V, the ST1S09PUR is versatile enough to be powered from various sources, including single-cell lithium-ion batteries, making it a perfect choice for mobile phones, digital cameras, and other handheld devices. Its ability to provide a continuous load current of up to 1.5A while maintaining high efficiency makes it suitable for powering core voltages of microprocessors and memory in portable electronics.

This step-down converter features a fixed output voltage that is factory preset from 1.8V to 3.3V in 100mV steps, allowing designers to select the version that best fits their system requirements without the need for external resistors. The high switching frequency of up to 1.5MHz enables the use of small surface-mount inductors and capacitors, thus reducing the overall footprint and cost of the power supply design.

The ST1S09PUR comes packed with protective features, including thermal shutdown, current limiting, and under-voltage lockout (UVLO), ensuring reliable operation under various conditions. Additionally, the device offers both PWM (Pulse Width Modulation) and PFM (Pulse Frequency Modulation) modes, which optimize the balance between efficiency and output voltage ripple, making it adaptable to a range of power-saving scenarios.

Available in a compact DFN6 (3x3mm) package, the ST1S09PUR minimizes the space required on the PCB and is an excellent choice for space-constrained applications. Its combination of efficiency, versatility, and compact form factor makes it an essential component for modern portable electronic designs.
