ST26C32ABTR - Quad Differential Line Receiver

The ST26C32ABTR is a quad differential line receiver designed to meet the stringent requirements of the industry standards for RS422 and RS423 serial communication. Manufactured by STMicroelectronics, a leader in semiconductor solutions, this integrated circuit is designed for high-speed, balanced communication applications.

Key Features

• Interface Standards: Compliant with RS422 and RS423 specifications.
• Quad Channels: Four independent receiver channels for handling multiple data streams.
• High Speed: Capable of operating at high speeds, making it suitable for advanced communication systems.
• Supply Voltage: Operates from a single 5V supply, simplifying power management in system design.
• Input Sensitivity: Features typical input sensitivity of 200 mV over the common-mode input voltage range.
• Temperature Range: Industrial temperature range from -40°C to +85°C, ensuring reliable performance under varying environmental conditions.
• Packaging: Available in a TSSOP package, providing a compact footprint for space-constrained applications.

Applications

The ST26C32ABTR is ideally suited for applications that require robust and reliable data transmission. It is commonly used in:

• Telecommunications systems
• Networking equipment
• Industrial control and automation
• Data acquisition systems

Reliability and Quality

STMicroelectronics is committed to delivering high-quality products. The ST26C32ABTR is built to offer excellent performance stability and reliability over its operational life. It undergoes rigorous testing and quality assurance processes to ensure it meets the industry standards and customer expectations.

Ordering Information

The product is available with the ordering code ST26C32ABTR and can be ordered through STMicroelectronics' distribution network or directly from their website.
