Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 900V
Continuous Drain Current at 25°C 2.1A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.5V @ 50μA
Max Gate Charge 27nC @ 10V
Max Input Capacitance 485pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 70W (Tc)
Maximum Rds On at Id,Vgs 6.5 Ohm @ 1.05A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 031129-STD2NK90ZT4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name STD2NK90
Introduction Date September 27, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian STD2NK90ZT4 CAD Model

Description

STD2NK90ZT4 - STMicroelectronics

The STD2NK90ZT4 is a high-performance N-channel Power MOSFET manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is part of STMicroelectronics' STPANK90Z series, designed to offer improved energy efficiency and thermal performance in a wide range of power management and switching applications.

Key Features

  • Voltage Rating: The STD2NK90ZT4 boasts a drain-source voltage (V<sub>DS) of 900V, making it suitable for high voltage applications.
  • Current Capacity: This MOSFET can handle a continuous drain current (I<sub>D) of up to 2.2A, providing robust performance for various electronic circuits.
  • Low On-Resistance: With an on-resistance (R<sub>DS(on)) of 3.9 ohms, this device ensures minimal power loss and increased efficiency in conducting mode.
  • High-Speed Switching: The STD2NK90ZT4 is designed for fast switching applications, which is essential for power supply and converter systems.
  • Gate Charge: It features a low gate charge (Q<sub>g), which reduces the energy required to turn the MOSFET on and off, further enhancing its efficiency.
  • Enhanced Durability: The MOSFET is encapsulated in a DPAK (TO-252) package, offering robustness and improved thermal dissipation.

Applications

The STD2NK90ZT4 is ideal for a diverse range of high voltage applications, including:

  • Switch Mode Power Supplies (SMPS)
  • LED Lighting
  • DC-DC Converters
  • Motor Control
  • Power Management Functions

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STD2NK90ZT4 is built to meet stringent quality standards, ensuring reliability and performance in even the most demanding environments. It is RoHS compliant and designed to meet or exceed industry standards for performance and longevity.

Summary

In summary, the STD2NK90ZT4 from STMicroelectronics is a versatile and efficient N-channel Power MOSFET suitable for a broad range of high voltage applications. Its low on-resistance, high-speed switching capabilities, and robust package design make it an excellent choice for designers looking to optimize their power management systems.
