Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 400V
Continuous Drain Current at 25°C 5.4A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.5V @ 50μA
Max Gate Charge 26nC @ 10V
Max Input Capacitance 535pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 70W (Tc)
Maximum Rds On at Id,Vgs 1 Ohm @ 2.7A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 031161-STD7NK40ZT4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name STD7NK40Z
Introduction Date July 23, 2002
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian STD7NK40ZT4 CAD Model

Description

STMicroelectronics STD7NK40ZT4 N-Channel MOSFET

The STD7NK40ZT4 is a high-performance N-channel MOSFET from the renowned semiconductor manufacturer STMicroelectronics. This power MOSFET is designed to offer exceptional efficiency and power density, making it an ideal choice for a wide range of applications that require efficient power conversion and switching. With its advanced technology and robust design, the STD7NK40ZT4 is tailored to meet the stringent requirements of modern electronic circuits.

Featuring a drain-source voltage (V<sub>DS) of 400V, the STD7NK40ZT4 is capable of handling high voltage applications with ease. Its maximum continuous drain current (I<sub>D) is rated at 7A, ensuring that it can support significant current loads without compromising performance. The device's low on-resistance (R<sub>DS(on)) minimizes power losses and improves overall efficiency, which is crucial for energy-sensitive designs.

The STD7NK40ZT4 comes in a surface-mount DPAK (TO-252) package, which is widely recognized for its compact footprint and excellent thermal performance. This package allows for efficient heat dissipation, ensuring the MOSFET operates within safe temperature ranges even under high power conditions. The device is also characterized by its fast switching speed, which is instrumental in reducing switching losses and improving the performance of power supply circuits, motor drives, and other high-speed switching applications.

STMicroelectronics has integrated multiple protection features into the STD7NK40ZT4 to enhance its reliability and longevity. These include a robust gate oxide layer and improved avalanche ruggedness, providing additional security against overvoltage and overload conditions. The MOSFET is also compliant with RoHS regulations, making it an environmentally friendly choice for designers and manufacturers looking to create green products.

In summary, the STD7NK40ZT4 from STMicroelectronics is a superior N-channel MOSFET that combines high voltage capability, low on-resistance, fast switching, and a compact package. Its performance and reliability make it a go-to component for engineers seeking to optimize their power management solutions.
