STEVAL-CCA014V1 - Audio Power Amplifier Demonstration Board by STMicroelectronics

The STEVAL-CCA014V1 is a state-of-the-art demonstration board from STMicroelectronics, specifically designed for audio applications. This product showcases the exceptional performance of the TDA7491LP dual BTL class-D audio amplifier, which is capable of delivering high-quality sound with high efficiency and minimized power dissipation.

Key Features


• Integrated TDA7491LP dual BTL class-D audio amplifier

• Up to 2 x 10W output power into 8Ω at 18V

• High efficiency with over 90% power efficiency

• Wide supply voltage range from 8V to 26V

• Single-ended or differential input signals

• Adjustable gain settings with external gain resistors

• Thermal protection and overcurrent protection

• RoHS compliant and designed to meet international standards


Applications

The STEVAL-CCA014V1 is ideal for a variety of audio applications, including:


• Home audio systems

• Active speakers

• Portable audio applications

• TV sound systems

• PC audio power amplifiers


Design Advantages

The board's design is focused on delivering high-quality audio performance with minimal power loss. The inclusion of the TDA7491LP ensures that users benefit from a compact solution with low thermal footprint. The STEVAL-CCA014V1 is also engineered for ease of use, featuring a plug-and-play approach that allows quick integration into existing audio setups.

Why Choose STEVAL-CCA014V1?

For developers and audio enthusiasts looking for an efficient, high-performance audio amplifier solution, the STEVAL-CCA014V1 offers a compelling option. Its combination of power, efficiency, and sound quality, along with the robust protection features, makes it suitable for a wide range of audio applications. Furthermore, STMicroelectronics' reputation for quality and reliability ensures that the STEVAL-CCA014V1 is a product that can be trusted for both prototype developments and end-user products.
