Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - LED Drivers
Mfr STMicroelectronics
Package Bulk
Product Status Obsolete
Outputs and Type 1, Non-Isolated
Voltage - Output 3.5V
Features 1V Start up Input Voltage
Voltage - Input 1V ~ 5.5V
Supplied Contents Board(s)
Utilized IC / Part L6920
Other Names 1026-STEVAL-ILL008V1,497-5516
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1283844-STEVAL-ILL008V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ILL008V1 CAD Model

Description

STEVAL-ILL008V1 - LED Driver Evaluation Board from STMicroelectronics

The STEVAL-ILL008V1 is an advanced evaluation board designed by STMicroelectronics, specifically tailored for LED lighting applications. This innovative platform is designed to showcase the capabilities of the L6562A, a transition-mode Power Factor Corrector (PFC) controller, and the L6385E, a high-voltage half-bridge driver with embedded comparator and operational amplifier.

This evaluation board is an excellent tool for engineers and designers looking to explore and prototype high-efficiency LED driver solutions. It is ideal for testing and evaluating various aspects of LED lighting systems, including power factor correction, efficiency, and dimming capabilities.

Key Features:

  • High-Efficiency PFC: The L6562A controller ensures high power factor and low THD (Total Harmonic Distortion), making the STEVAL-ILL008V1 suitable for energy-sensitive applications.
  • Flexible Power Supply: The board can be powered from a wide AC input voltage range, accommodating various regional power standards.
  • Dimming Support: The evaluation board includes provisions for implementing both analog and digital dimming techniques, offering versatility for different lighting scenarios.
  • Thermal Protection: Features include overtemperature protection, safeguarding the board and components during high-temperature operation.
  • Robust Design: The STEVAL-ILL008V1 is designed to handle surges and transients, ensuring longevity and reliability in harsh electrical environments.

The board's layout is optimized for minimal noise and interference, which is crucial for the performance of sensitive lighting systems. It also provides several test points for easy measurement and evaluation of the circuit parameters.

Whether for industrial, commercial, or residential lighting applications, the STEVAL-ILL008V1 from STMicroelectronics is an excellent starting point for developing advanced LED lighting solutions that require efficient power management and high reliability.
