STEVAL-ILL020V1 STMicroelectronics – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Current - Output / Channel 30mA
Outputs and Type 6 Non-Isolated Outputs
Voltage - Output 36V
Features Dimmable
Voltage - Input 4.5V ~ 36V
Contents Board(s)
Utilized IC / Part LED7706
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1569286-STEVAL-ILL020V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ILL020V1 CAD Model
