Products specifications

Categories Development Boards, Kits, Programmers
Manufacturer STMicroelectronics
Series VIPER
Part Status Obsolete(EOL)
Main Purpose AC/DC, Primary Side
Outputs and Type 1, Isolated
Power - Output 125W
Voltage - Output 19V
Output Current 6.6A
Voltage - Input 240 V ~ 400 V
Regulator Topology Flyback
Frequency - Switching 55kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part L6565, STP12IE95F4
Win Source Part Number 795768-STEVAL-ISA041V1
Popularity Medium
Supply and Demand Status Limited
Family Name STEVAL-ISA041V1
Introduction Date April 16, 2010
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA041V1 CAD Model

Description

STEVAL-ISA041V1 - STMicroelectronics Voltage Regulator Evaluation Board

The STEVAL-ISA041V1 from STMicroelectronics is a cutting-edge evaluation board designed for testing the performance and capabilities of the L7986A, a highly efficient DC-DC converter. This evaluation board is a part of STMicroelectronics' extensive range of product evaluation tools, offering an accessible platform for engineers and developers to analyze and validate their power supply and voltage regulation designs.

At the heart of the STEVAL-ISA041V1 is the L7986A, a step-down switching regulator that delivers up to 3A of continuous current with excellent line and load regulation. The L7986A operates over a wide input voltage range from 4.5V to 38V, making the STEVAL-ISA041V1 suitable for a variety of applications, including industrial, automotive, and consumer electronics.

The evaluation board showcases the L7986A's features, such as its adjustable switching frequency, which can be set from 200 kHz to 1.5 MHz, allowing flexibility in the design of the associated passive components. This adaptability ensures that users can optimize the size and response characteristics of their power supply solution. Additionally, the L7986A boasts a peak efficiency of up to 95%, ensuring minimal energy loss during the voltage conversion process.

The STEVAL-ISA041V1 evaluation board comes equipped with a range of protection features, including overcurrent protection, thermal shutdown, and overvoltage protection, which safeguard the board and the components from potential damage due to abnormal operating conditions. The board is also designed with test points that provide convenient access for measuring the electrical parameters, ensuring an efficient and user-friendly evaluation experience.

For developers seeking to customize their applications, the STEVAL-ISA041V1 provides the ability to adjust the output voltage, enabling the creation of tailored power solutions that meet specific requirements. The compact size of the board, along with its comprehensive documentation, makes it an ideal tool for rapid prototyping and expedited development cycles.

In conclusion, the STEVAL-ISA041V1 evaluation board is an invaluable resource for professionals looking to harness the power and versatility of the L7986A voltage regulator in their designs. With its robust feature set and user-friendly interface, it represents an essential tool for developing efficient and reliable power supply solutions.
