Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - LED Drivers
Mfr STMicroelectronics
Package Bulk
Current - Output / Channel 700mA
Outputs and Type 1, Isolated
Voltage - Output 60V ~ 110V
Voltage - Input 90 ~ 300 VAC
Supplied Contents Board(s)
Utilized IC / Part HVLED001A
Base Product Number STEVAL
Other Names -1138-STEVAL-LLL006V1,497-19791
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
HTSUS 0000.00.0000
Win Source Part Number 1283852-STEVAL-LLL006V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-LLL006V1 CAD Model

Description

STEVAL-LLL006V1 from STMicroelectronics

The STEVAL-LLL006V1 is an innovative evaluation board designed by STMicroelectronics, tailored for the development and testing of advanced lighting solutions. This board is a part of ST's LED1202 product family, which is known for its exceptional efficiency and performance in driving LED arrays.

At the heart of the STEVAL-LLL006V1 is the LED1202 12-channel LED driver with independent 12-bit PWM dimming capability for each channel. This allows for precise control over brightness and color mixing, which is essential for applications requiring sophisticated lighting effects, such as architectural lighting, mood lighting, or LCD backlighting.

The evaluation board operates over a wide input voltage range, making it suitable for a variety of power supply conditions. Additionally, the LED1202's built-in error detection features, such as open-LED and short-LED detection, ensure reliable operation and extend the longevity of your lighting application.

The STEVAL-LLL006V1 is equipped with an intuitive user interface that includes jumpers and test points to simplify configuration and testing. This user-friendly approach makes it accessible for both professionals and hobbyists to experiment with and optimize their lighting designs.

Integration with the STSW-LED1202FW firmware package provides a comprehensive software platform for controlling the LED driver via an I2C interface. This enables seamless communication with microcontrollers and facilitates rapid prototyping and development.

To assist with real-world deployment, the STEVAL-LLL006V1 also features a compact design, ensuring it can be easily integrated into a wide range of products and applications. Whether you're developing cutting-edge commercial lighting systems or innovative home automation projects, the STEVAL-LLL006V1 offers the flexibility and performance needed to bring your ideas to light.

Overall, the STEVAL-LLL006V1 is a testament to STMicroelectronics' commitment to providing advanced tools for the development of state-of-the-art lighting solutions. With its robust design, powerful features, and user-centric approach, it stands as an indispensable asset for engineers and designers aiming to push the boundaries of lighting technology.
