Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Switch Circuit SPDT
Number of Circuits 4
Max On Resistance 5.2 Ohm
Channel-to-Channel Matching (ΔRon) 300 mOhm
Single Supply Voltage (V+) 1.65 V to 4.3 V
Max Switch Time (Ton,Toff) 15ns, 5ns
-3db Bandwidth 800MHz
Charge Injection 5pC
Channel Capacitance(CS off, CD off) 5pF
Max Leakage Current (IS off) 20nA
Crosstalk -78dB @ 1MHz
Temperature Range - Operating -55°C to 125°C (TA)
Case / Package 16-QFN (2.6x1.8)
Win Source Part Number 031188-STG3693QTR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name STG3693
Introduction Date January 03, 2006
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian STG3693QTR CAD Model

Description

STG3693QTR from STMicroelectronics is an interface component in the analog switch, multiplexer, and demultiplexer category, commonly evaluated for signal routing, channel selection, and compact analog front-end designs. Engineers typically consider parts in this class for portable electronics, data acquisition paths, industrial control boards, communication equipment, and embedded systems where flexible signal management is required. Its value lies in helping simplify board layouts, reduce the need for discrete switching networks, and support space-conscious designs from prototype through volume production. For sourcing and long-term design planning, the current lifecycle status for STG3693QTR is information not available, so supply-chain teams should verify availability and manufacturer status before committing to new designs. RoHS compliance information is also not available in the provided data. Designers and buyers should confirm the latest environmental compliance declarations, datasheet details, and any material disclosure documents directly from STMicroelectronics or authorized distribution channels.
