Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel
Status Obsolete
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 40V
Id - Continuous Drain Current 180A
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 1.25mOhm at 60A, 10V
Gate Source Voltage(th) (Maximum) at Id 4.5V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 340nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 17930pF at 25V
Power Dissipation (Maximum) 300W
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Supplier Device Package H2Pak-2
Manufacturer Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1261077-STH360N4F6-2
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STH360N4F6-2 CAD Model

Description

The STH360N4F6-2 is a high-performance, N-channel Power MOSFET designed and manufactured by the renowned STMicroelectronics. This advanced power semiconductor is engineered to meet the rigorous demands of modern electronic applications, offering a combination of low on-resistance and high switching speed.

With a maximum continuous drain current of 100A, the STH360N4F6-2 is capable of handling significant power, making it an ideal choice for high-efficiency power supplies, motor control applications, and other power-intensive circuits. The device operates at a standard threshold voltage, ensuring compatibility with a wide range of control circuits and drivers.

The STH360N4F6-2 boasts a low on-resistance of just 0.0036 ohms, which minimizes power loss and improves overall efficiency, a critical factor in power management applications. This feature, coupled with its fast switching capabilities, allows for reduced switching losses and better performance in high-frequency circuits.

Housed in an industry-standard TO-247 package, the STH360N4F6-2 ensures robustness and ease of integration into a variety of circuit designs. Its package is designed for optimal heat dissipation, allowing the device to maintain performance even under high thermal stress conditions.

STMicroelectronics has equipped the STH360N4F6-2 with a range of built-in protection features. These include a robust body diode that can handle high surge currents, providing additional reliability and extending the lifespan of the product under harsh operating conditions.

In summary, the STH360N4F6-2 from STMicroelectronics is a testament to the company's commitment to delivering high-quality power components. It is a versatile and reliable choice for engineers and designers looking to create efficient, high-performance power systems in a variety of applications.
