Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Active
Core Processor ARM Cortex-M3
Part Core Size 32-Bit
Speed(Frequency) 72MHz
Number of I/O 37
Program Memory Size 128KB (128K x 8)
Program Memory Type FLASH
Data RAM Size 20K x 8
Supply Voltage - Operating 2 V to 3.6 V
Data Converters A/D 10x12b
Temperature Range - Operating -40°C to 105°C (TA)
Case / Package 48-LQFP (7x7)
Win Source Part Number 031275-STM32F103CBT7
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STM32F103CBT7 CAD Model

Description

STM32F103CBT7 Microcontroller

The STM32F103CBT7 is a performance line microcontroller from STMicroelectronics, which is part of their well-known STM32 family. It features a 32-bit ARM Cortex-M3 RISC core operating at a frequency of up to 72 MHz. This microcontroller is designed to offer a balanced combination of performance, power efficiency, and embedded features to handle a variety of applications ranging from industrial control systems to medical devices.

Key Features:

  • Core: ARM Cortex-M3 32-bit RISC core running at up to 72 MHz.
  • Memory: 128 KB of Flash memory and 20 KB of SRAM, allowing for robust program storage and efficient data handling.
  • I/O Ports: Up to 37 I/O ports and 2 I/O analogs, providing ample connectivity options for peripherals and sensors.
  • Communication Interfaces: Includes a variety of communication interfaces such as I2C, SPI, USART, USB, and CAN, enabling the microcontroller to connect with other devices and form complex communication networks.
  • ADC: 12-bit, 1 μs Analog-to-Digital Converters (ADCs), providing precise measurements for analog signals.
  • Timers: Multiple timers including 3 general-purpose and 1 advanced control timer for scheduling tasks and managing time-sensitive operations.
  • Debugging: Integrated debugging and programming features through Serial Wire Debug (SWD) & JTAG interfaces.
  • Power Efficiency: Features several power-saving modes, including Sleep, Stop, and Standby modes to optimize power consumption for battery-powered or energy-conscious applications.
  • Package: Available in a 48-pin LQFP package that is suitable for space-constrained applications while still offering sufficient I/O capabilities.

Applications:

The STM32F103CBT7 microcontroller is versatile and can be used in a diverse set of applications. Its robust feature set makes it ideal for motor drive and application control, medical and handheld equipment, PC peripherals, gaming and GPS platforms, industrial applications, PLCs, inverters, printers, and scanners, alarm systems, video intercom, and HVAC systems.

Conclusion:

With its high-performance ARM Cortex-M3 core, extensive range of peripherals, and low power consumption, the STM32F103CBT7 from STMicroelectronics is a reliable choice for designers looking to develop advanced embedded systems with stringent performance and power efficiency requirements.
