Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tray
Status Active
Core Processor ARM Cortex-M3
Part Core Size 32-Bit
Speed(Frequency) 120MHz
Number of I/O 82
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
Data RAM Size 132K x 8
Supply Voltage - Operating 1.8 V to 3.6 V
Data Converters A/D 16x12b; D/A 2x12b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 100-LQFP (14x14)
Win Source Part Number 031307-STM32F207VCT6
Family Name STM32F207VC
Introduction Date June 05, 2009
ECCN 3A991.a.2
Country of Origin China, Malaysia, Philippines, Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STM32F207VCT6 CAD Model

Description

STM32F207VCT6 Microcontroller - STMicroelectronics

The STM32F207VCT6 is a high-performance microcontroller from STMicroelectronics that belongs to the STM32F2 series, which is based on the ARM Cortex-M3 32-bit RISC core operating at a frequency of up to 120 MHz. This microcontroller is designed for applications that require a balance between performance, power efficiency, and cost, making it an ideal choice for a wide range of industrial, medical, and consumer applications.

Key Features:

  • Core: ARM Cortex-M3 processor, which includes a 3-stage pipeline, supports Thumb-2 instruction set, and delivers exceptional efficiency in both speed and power consumption.
  • Memory: 256 KB of Flash memory and 64 KB of SRAM, providing ample space for complex applications and data storage.
  • Connectivity: A rich set of I/Os and peripherals including Ethernet, USB OTG HS/FS, CAN, several serial interfaces (I2C, SPI, USART), 12-bit ADCs, 12-bit DACs, and much more.
  • Performance: A high-performance architecture with a single-cycle multiplication and hardware division, delivering up to 120 DMIPS when running at 120 MHz.
  • Timer Features: Advanced control timer, up to four 16-bit timers, up to two watchdog timers, SysTick timer, and a low-power timer.
  • Debugging and Development: In-circuit debugging and programming is facilitated via the Serial Wire Debug (SWD) and JTAG interfaces, along with enhanced trace and debug capabilities through the Embedded Trace Macrocell (ETM).
  • Power Efficiency: Features multiple power-down modes for optimized power consumption, including Sleep, Stop, and Standby modes.
  • Package: Supplied in a 100-pin LQFP package, which is ideal for space-constrained applications.

Applications:

The STM32F207VCT6 is versatile enough to be used in a range of applications, such as motor drive and application control, medical equipment, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercom, and HVAC systems.

Conclusion:

With its high CPU performance, a comprehensive set of peripherals, and low-power consumption, the STM32F207VCT6 from STMicroelectronics is a robust and reliable microcontroller choice for designers looking to balance performance, power, and cost. Its wide range of features and connectivity options ensure it can meet the needs of complex and demanding applications.
