Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 120A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 210nC @ 10V
Max Input Capacitance 5100pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 310W (Tc)
Maximum Rds On at Id,Vgs 3.7 mOhm @ 90A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 026243-STP200NF04
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STP200NF04 CAD Model

Description

STP200NF04 - N-Channel MOSFET from STMicroelectronics

The STP200NF04 is a high-performance N-channel Power MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This MOSFET is designed to deliver superior switching performance and high current handling capabilities, making it an ideal choice for a wide range of power applications.

With a drain-source voltage (V<sub>DS) of 40V and a continuous drain current (I<sub>D) of 120A, the STP200NF04 MOSFET is well-suited for high-efficiency power conversion tasks in both industrial and automotive environments. Its low on-state resistance (R<sub>DS(on)) of just 4.5 mΩ (max) at V<sub>GS = 10 V ensures minimal power loss during operation, contributing to energy savings and reduced heat dissipation.

The STP200NF04 features a robust and rugged design, with an extended operating temperature range, which ensures reliability even under harsh conditions. Its 100% avalanche tested design provides additional protection against unexpected voltage spikes, making it a reliable choice for safety-critical applications.

For ease of integration into various circuit designs, the STP200NF04 comes in a TO-220 package, which is widely recognized and easy to handle. This package is compatible with a variety of mounting and soldering techniques, providing flexibility for both prototyping and mass production.

Applications for the STP200NF04 are diverse and include high-efficiency DC/DC converters, motor drives, and power management systems. Its high current capability also makes it suitable for load switching and pulse applications where fast switching is required.

STMicroelectronics provides comprehensive technical support for the STP200NF04, including detailed datasheets, application notes, and design resources to assist engineers in integrating this MOSFET into their designs effectively. With its combination of performance, reliability, and support, the STP200NF04 is an excellent choice for professionals seeking a high-quality power MOSFET solution.
