Products specifications Report Issue?

Categories Discrete Semiconductor Products
Features Diode Array 1 Pair Common Cathode Schottky 60 V 10A Through Hole TO-220-3
Manufacturer STMicroelectronics
Package Tube
Part Status Obsolete
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Through Hole
Package TO-220-3
Case / Package TO-220AB Narrow Leads
Family Name STPS20
MSL Level Not Applicable
ECCN EAR99
HTSUS 8541.10.0080
Quantity per package 2000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 935607-STPS20L60CTN
Ultra Librarian 3D Model Ultra Librarian STPS20L60CTN CAD Model

Description

STPS20L60CTN - Power Schottky Rectifier from STMicroelectronics

The STPS20L60CTN is a robust and high-performance Power Schottky Rectifier designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This component is part of ST's Schottky diode portfolio, and it is specifically engineered to meet the demands of high efficiency and reliability in power management applications.

With a repetitive peak reverse voltage (V<sub>RRM) of 60V and an average forward current (I<sub>F(AV)) of 20A, the STPS20L60CTN is well-suited for high-frequency power switching in a variety of electronic devices. The dual center tap configuration allows for flexibility in design, making it ideal for use in switch-mode power supplies (SMPS), converters, free-wheeling diodes, and reverse battery protection circuits.

The STPS20L60CTN boasts a low forward voltage drop (V<sub>F), which enhances the efficiency of the overall system by reducing power dissipation and improving thermal performance. This characteristic is particularly valuable in applications where energy conservation is critical, such as in portable devices and renewable energy systems.

Constructed with ST's advanced Schottky technology, the device offers superior switching performance and a reduced leakage current over a wide temperature range, ensuring reliability and longevity even under harsh operating conditions. The high junction temperature capability (T<sub>J) extends the thermal margin, allowing for operation in high-temperature environments without compromising performance.

The STPS20L60CTN comes in a TO-220AB package, which is widely recognized for its mechanical robustness and ease of mounting on a heatsink, facilitating effective thermal management. The package is also designed for optimal electrical isolation, enhancing the safety of the application it is used in.

In conclusion, the STPS20L60CTN from STMicroelectronics is a high-quality, versatile Schottky rectifier that offers designers a combination of efficiency, reliability, and performance. Its advanced features make it an excellent choice for modern power conversion applications where component excellence is paramount.
