Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Triac Type Logic - Sensitive Gate
Voltage - Off State 600V
Current - On State (It (RMS)) (Max) 4A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 30A, 31A
Current - Gate Trigger (Igt) (Max) 5mA
Current - Hold (Ih) (Max) 10mA
Configuration Single
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting Through Hole
Case / Package I-Pak
Win Source Part Number 056382-T405-600H
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian T405-600H CAD Model

Description

The T405-600H is a high-performance triac produced by STMicroelectronics, a leader in semiconductor solutions. This triac is part of the T series, designed for AC load control applications. It offers a bidirectional switching capability and is particularly suitable for the on/off function in applications such as motor control, heating, lighting, and static switching.

Key Features

  • Current Rating: The T405-600H can handle a maximum RMS current of 4 A, making it suitable for moderate power applications.
  • Repetitive Peak Off-state Voltage (Vdrm): With a peak off-state voltage of 600 V, this triac can be used in circuits with high peak voltages, providing a high level of voltage insulation and robustness.
  • Gate Trigger Current (Igt): The triac has a low gate trigger current of 35 mA, which allows it to be easily driven by microcontrollers and other low-power gate trigger circuits.
  • Snubberless Technology: The device incorporates ST's snubberless technology, which enhances its capability to handle inductive loads without the need for additional external components, simplifying circuit design and reducing costs.
  • High Commutation Performance: It features high commutation performance, which is critical for applications that require frequent turning on and off, ensuring reliability and longevity.

Applications

The T405-600H is versatile and can be used in a variety of applications, including:

  • Home appliances (e.g., washing machines, vacuum cleaners, and kitchen appliances)
  • Motor control circuits
  • Lighting systems (e.g., dimmers and fluorescent lighting)
  • Heating systems
  • Power tools

Quality and Reliability

STMicroelectronics ensures that the T405-600H meets the highest standards of quality and reliability. The device is compliant with RoHS and Halogen-free, making it an environmentally friendly choice for modern electronic applications. With its robust design and tested performance, the T405-600H is a solid choice for designers looking for a reliable triac solution.
