Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Type Class AB
Output Type 4-Channel (Quad)
Max Output Power x Channels at Load 75W x 4 at 2Ohm
Supply Voltage (V) 8V ~ 18V
Features I2C, Mute, Short-Circuit and Thermal Protection, Standby
Mounting Style Through Hole
Temperature Range - Operating -55°C ~ 150°C
Supplier Device Package 27-Flexiwatt (Vertical)
Manufacturer Package 27-Flexiwatt (Formed Leads)
Family Part Number TDA7563A
Manufacturer Pack Quantity 17
MSL Level 1 (Unlimited)
Win Source Part Number 1266244-TDA7563A
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TDA7563A CAD Model

Description

STMicroelectronics TDA7563A Multifunction Quad Power Amplifier

The TDA7563A from STMicroelectronics is a cutting-edge multifunction quad power amplifier designed to provide a high-quality audio experience for automotive applications. This robust and flexible integrated circuit is built to enhance in-car audio systems, delivering exceptional sound quality with high power efficiency.

Key Features

  • High Output Power: Capable of delivering up to 4 x 50W of continuous output power, the TDA7563A ensures loud and clear sound reproduction, making it ideal for an immersive audio experience in the challenging car environment.
  • Flexiwatt27 Package: The device comes in a Flexiwatt27 package, which is designed for heat dissipation and space-saving, making it a practical choice for compact automotive audio systems.
  • Advanced Diagnostics: Integrated diagnostics facilities enable the detection of output AC/DC short circuits to ground or to the supply voltage, helping to prevent damage to the amplifier and the speakers.
  • Multiple Switching Modes: The TDA7563A features various switching modes, including the Standby and Mute functions, providing flexibility and control over the audio output.

Performance and Protection

With an emphasis on reliability, the TDA7563A incorporates several protection features. It offers a clip detector, as well as a protection system against over-temperature and overload conditions. These safeguard measures ensure the longevity of the amplifier and connected components, even under strenuous operating conditions.

Applications

Primarily designed for automotive audio applications, the TDA7563A is versatile enough to be used in any system where high-quality audio amplification is required. It is particularly suitable for car radios, CD and MP3 players, and full-featured multimedia receivers.

Conclusion

The TDA7563A from STMicroelectronics represents a powerful solution for modern automotive audio systems. Its combination of high power output, advanced features, and robust protection circuits makes it an excellent choice for manufacturers and hobbyists alike who are looking to create superior in-car audio experiences.
