Products specifications Report Issue?

Manufacturer STMicroelectronics
Standard Package 30
Category Discrete Semiconductor Products
Family Transistors (BJT) - Single
Packaging Tube
Transistor Type NPN - Darlington
Current - Collector (Ic) (Max) 10A
Voltage - Collector Emitter Breakdown (Max) 100V
Vce Saturation (Max) @ Ib Ic 3V @ 40mA 10A
Current - Collector Cutoff (Max) 2mA
DC Current Gain (hFE) (Min) @ Ic Vce 1000 @ 5A 4V
Power - Max 125W
Mounting Style Through Hole
Package TO-247-3
Manufacturer Device Package TO-247-3
Catalog NPN Transistors
Kits 497-8005-KIT - KIT TRANSISTOR NPN/PNP 22VAL 5EA
Win Source Part Number 092002-TIP142
Family Name TIP142
Introduction Date March 20, 2000
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian TIP142 CAD Model

Description

The TIP142 is a silicon NPN Darlington power transistor designed and manufactured by STMicroelectronics. It is a robust and reliable component that is widely used in various electronic applications. The TIP142 is characterized by its high current gain and integrated anti-saturation circuit, making it an optimal solution for inductive loads where switching precision and efficiency are crucial.

With a collector-emitter voltage (V<sub>CEO) of 100V and collector current (I<sub>C) rating of up to 10A, the TIP142 is capable of handling high power applications with ease. Its high current gain is due to the Darlington configuration, which pairs two bipolar transistors in such a way that the current amplified by the first is amplified further by the second. This results in a high overall current gain, which is beneficial for applications requiring a high level of amplification.

The TIP142 is packaged in a TO-247 package, which is known for its excellent power dissipation capabilities. This allows the transistor to operate at higher temperatures and manage higher power levels without the risk of overheating. Additionally, the TO-247 package is designed for easy mounting on heat sinks, which further enhances its thermal performance.

This transistor is particularly suitable for linear and switching applications. It is commonly used in power regulators, DC-DC converters, motor control circuits, and audio amplifiers. Its ability to drive large loads makes it a preferred choice for designers in the field of power electronics.

STMicroelectronics provides comprehensive technical support for the TIP142, offering detailed datasheets, application notes, and design resources. This ensures that engineers can fully utilize the capabilities of the TIP142 in their designs and achieve the best possible performance in their applications.

In summary, the TIP142 from STMicroelectronics is a high-performance NPN Darlington power transistor that offers a combination of high voltage and current handling capabilities, excellent thermal performance, and a high current gain. Its robustness and reliability make it an excellent choice for demanding power applications.
