Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Status Obsolete
Amplifier Type J-FET
Slew Rate 16V/μs
Gain Bandwidth Product 4MHz
Current - Input Bias 20pA
Voltage - Input Offset 3mV
Supply Current 1.4mA
Current - Output / Channel 40mA
Supply Voltage , Single/Dual (±) 6V ~ 36V, ±3V ~ 18V
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SO
Family Part Number TL072
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1267921-TL072ACD
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TL072ACD CAD Model

Description

Overview of Product TL072ACD from STMicroelectronics

The TL072ACD is a high-performance JFET-input operational amplifier from STMicroelectronics, designed to offer a perfect blend of features for a wide range of applications. This dual operational amplifier integrates low-noise and low-harmonic distortion, making it an ideal choice for audio pre-amplification, high-fidelity systems, and various signal processing tasks where low noise is a critical parameter.

Key Features

  • Low Power Consumption: The TL072ACD is designed for efficient operation, minimizing power usage without sacrificing performance. This makes it suitable for battery-operated devices.
  • Low Input Bias and Offset Currents: The device is engineered to have very low input currents, reducing errors and improving accuracy in applications such as integrators or active filters.
  • High Input Impedance: The JFET input stage provides high input impedance, which ensures minimal loading on the source circuit.
  • Output Short-Circuit Protection: The TL072ACD comes with built-in short-circuit protection, enhancing the reliability and robustness of the device in various operating conditions.
  • Internal Frequency Compensation: The device is internally frequency compensated, which simplifies design considerations by removing the need for external components.
  • Low Harmonic Distortion: It is designed to have low total harmonic distortion, making it a preferred choice for high-fidelity audio applications.

Applications

The TL072ACD is versatile and can be used in a plethora of applications. It is commonly found in:

  • Audio Pre-Amplifiers and Mixers
  • Active Filters
  • Signal Processing Equipment
  • Analog-to-Digital Converters
  • Servo Amplifiers
  • Instrumentation

Package Information

The device is available in a SO-8 package, which is compact and suitable for space-constrained applications. The small footprint of the TL072ACD allows it to be integrated into various circuit designs without requiring significant board space.

In summary, the TL072ACD operational amplifier by STMicroelectronics is a reliable and efficient solution for designers looking to improve signal amplification with minimal noise and distortion. Its robust feature set and versatility make it a valuable component in both consumer and professional audio applications, as well as precision analog circuits.
