The TL084IDT, manufactured by STMicroelectronics, is a high-speed JFET-input quad operational amplifier that combines low power consumption with a wide bandwidth and improved output drive capability. This amplifier is part of the TL08x series, which is well-suited for applications requiring low noise, high input impedance, and fast settling time.

Key Features

• Wide Common-Mode (up to VCC+) and Differential Voltage Range
• Low Input Bias and Offset Current
• Output Short-Circuit Protection
• High Input Impedance JFET Input Stage
• Internal Frequency Compensation
• Latch-Up Free Operation
• High Slew Rate: 16 V/μs (typical)
• Low Power Consumption: 1.4 mA/channel (typical)
• Wide Gain Bandwidth: 4 MHz (typical)

Applications

The TL084IDT is versatile and can be used in an array of electronic applications such as:

• Summing Amplifiers
• Voltage Followers
• Integrators or Differentiators
• Active Filters
• Function Generators
• Analog Delay Lines
• Audio, Instrumentation, and Medical Applications

Product Specifications

The device operates over a wide range of power supplies, from +/- 5V to +/- 15V, and features a low harmonic distortion. The TL084IDT is available in an SO-14 package, making it compact and suitable for space-constrained applications. It also offers an extended temperature range, functioning reliably over a -40°C to 105°C range, which makes it ideal for industrial environments.

Quality and Reliability

STMicroelectronics is committed to providing high-quality products. The TL084IDT operational amplifier is designed and manufactured to meet the rigorous standards of the industry, ensuring both reliability and performance for the end-user.

With its combination of features, the TL084IDT is a solid choice for designers looking for a general-purpose operational amplifier that offers flexibility, reliability, and performance.
