Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type 555 Type, Timer/Oscillator (Single)
Frequency 2.7MHz
Supply Voltage - Operating 2 V to 16 V
Operating Supply Current 65μA
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SO
Mounting Surface Mount
Win Source Part Number 145344-TS555IDTTR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TS555IDTTR CAD Model

Description

Product Overview: TS555IDTTR - STMicroelectronics

The TS555IDTTR from STMicroelectronics is a high-performance, low-power, single CMOS timer that offers a significant upgrade to the standard 555 timer capabilities. It is designed to operate in a wide range of timing and pulse generation applications, providing reliable performance in a compact SMD package. This versatile component is an ideal choice for precision timing solutions in a variety of electronic devices.

Key Features

  • Low Power Consumption: The TS555IDTTR operates with a reduced supply current when compared to bipolar timers, making it ideal for battery-operated devices.
  • High Frequency: Capable of producing accurate time delays and oscillations, the timer can operate at frequencies up to 2.7MHz.
  • Wide Voltage Range: This timer supports a supply voltage range from 2.7V to 16V, providing flexibility for various application requirements.
  • Adjustable Duty Cycle: Users can set the duty cycle from 50% to 100%, allowing for a range of pulse-width modulation options.
  • Output Drive Capability: The output can sink or source up to 100mA, which is sufficient to drive TTL loads or provide direct power to small relays and LEDs.
  • Temperature Stability: The TS555IDTTR maintains stable timing over a temperature range from -40°C to 85°C.
  • ESD Protection: Enhanced electrostatic discharge protection is included to ensure device integrity during handling and operation.

Applications

The versatility of the TS555IDTTR makes it suitable for a wide range of applications, including:

  • Timing circuits
  • Pulse generation
  • Sequential timing
  • Time delay generation
  • Precision pulse width modulation (PWM)
  • Frequency division
  • Battery-operated devices

With its robust feature set and STMicroelectronics' commitment to quality, the TS555IDTTR is a reliable and efficient solution for designers looking to implement timing functions in their electronic projects.
